Mile 04 C

• Product Sheet
• Installation Manual
• Installation manual - Recessed canopy UL
• Installation manual - Recessed canopy CE
• 3D Files - Model C
• IES Files
• Recessed Canopy
• Colour temperature adjustment guide

powder coated or polished aluminum body
frosted opal acrylic diffuser
white powder coated aluminium canopy
powder coated steel anchor
polyester cord

Dimensions
Length:
C: 78.3 in / 199 cm
Height: Variable, min. 6 in / 15 cm
Depth: 2 in / 5.1 cm

Luminaire total height
(ceiling to lowest point of luminaire).
Min - 6 in / 15 cm
Max - 98 in / 249 cm + variable
*For any height outside these parameters, contact Lambert & Fils.

Cord Length
Main/line cords: 120 in / 304 cm
Non-electrical cords: 96 in / 244 cm

Weight
C: 5.2 lb / 2.3 kg

SourceLED array, integrated

Power Consumption
C: 40 W

Colour Temperature Options
3000K
2700K
2200K
Dim-to-warm 3000K to 2200K
Dim-to-warm 2700K to 2200K

Lumen Output
C: 2700K - 3169 lm
C: 3000K - 3267 lm

Colour Rendering Index
≥90 CRI

Colour Consistency
3 SDCM

Expected Lifetime
≥50,000 hours

Control Options
120-277V: On/Off, 0-10V or Phase dimming (120 V only)
220-240V: On/Off, Phase Dimming, DALI
Refer to our recommended list of dimmer models on the product sheet.

9 weeks

You will receive an email with an estimated delivery date when your order is completed.

If you’ve ordered lamps with various lead times, note they will be shipped together according to the longest lead time. If you require a shorter lead time, please contact us at order@lambertetfils.com, specifying the required shipment date, and we will confirm whether it is possible. An additional rush fee may apply.

Luminaire height is adjustable on site.

Luminaire can be installed on a slanted ceiling - 45° or less.

Dimensions are approximate and may vary slightly
